PWR-MOD-TYPE-C

Compact USB Type-C power module providing a 12 V output through a JST-PH connector for easy model and diorama power.

This product is still in development. Reach out if you'd like to be kept in the loop, or if you need something similar sooner.

Overview

The USB-C 12V Power Module provides a simple way to power models, dioramas and miniature electronics from a modern USB Type-C power supply.

The module negotiates a 12 V USB Power Delivery profile from a compatible USB-C PD power supply and makes the resulting 12 V supply available through a JST-PH connector.

This makes it possible to use readily available USB-C power adapters and power banks instead of requiring a dedicated 12 V power adapter, while keeping the connection to the model compact and easy to disconnect.

Designed as part of the Tiny-FX power ecosystem, it provides a convenient power entry point for lighting controllers, effects and other 12 V electronics.

Important: the connected USB-C power source must support a 12 V Power Delivery profile.

Technical specifications

Specifications are indicative and subject to change as the product moves through development.
